Feature:

High Quality, High Resolution, Clear Images
2.0MP Definition
Japan CMOS
Certificate:CE,FC,RoHS
Industry Cmos Camera. It can Show the live image directly on any VGA monitor or Projector.
It build in digital crosshairs and color control,add line in the pictures,freeze,Mirror,Rotate, Negative,Compare function
Supply USB2.0, VGA, CVBS three output ports.
Supply USB2.0 + VGA or USB2.0+CVBS output at the same time.
We sell much to the industy factory, then the works can see the problems directly in the Monitor.

Specification:

Model: Camera with VGA AV USB2.0 three output
Sensor: 2.0mp,1/3 inch
Full Resolution: 1600X1200 (UXGA)
800 lines Definition
Frame rate: 10-15(USB2.0)
720P/1024x768/1280x1024/1366x768@60HZ
White Balance: Auto
Light: Auto
Color: Color/B&W
Negative: Support
Morror: Left/right,Up/Down
Freeze: Support
OSD: English/Chinese
Picture compare: Captured picture dynamic video 1/2 screen compare
Contrast: Support
Saturation: Support
Cross cursor: Support,different color
Line: different color,2 horizontal line
2 vertical line,any positions
Digital Noise reducer: Support
VGA(RGB): 720P/1024x768/1280x1024/1366x768@60HZ
USB2.0


Stereo Table Stand Feature:

Need a Sturdy Boom Stand for reduced Vibration and Optimal Versatility? This stand provides what is needed!
This stand has a dual arm system with a counterweight on the opposite end of arm to counter the weight of your microscope head. This gives more stability compared with a common type of boom stand.
The multi-axis rotation feature allows this boom stand to locate your microscope head to most any position or angle. This can be a greatly needed tool when you have a hard-to-see location such as inspecting and searching for cracks on the solder of a circuit board.
We provide the boom stand only. This is not a complete system. A microscope head with optics is needed. You provide the head. We have several types of adapters to fit a variety of microscope heads. Contact us for details about your specific requirements so we can assist with a smooth fit.
Easy Large-Sized Focusing Knobs on Both Sides of Focusing Holder.
Steel Gears on Focusing Holder.
Standard Size Focusing Holder - Will Fit Scope Heads with Diameter of 50mm
Item size: see the 4th picture
Weight: 3.3kg

C-MOUNT Lens:

Working distance: 95mm
zoom c-mount Lens
0.5X C-mount adapter
zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display)
Size: 180mm(L) * 50mm(DIA)
Weight: 450g

Packing including:

1 x Microscope Camera
1 x 180X C-MOUNT Lens
1 x Power Supply
1 x USB Line
1 x Software DISC
1 x 56 LED Ring light
1 x Digital Microscope Table Stand
