Noting:

1:PC Support : Windows XP/7/8/10 system

2:For USB output, the white balance, exposure and color adjustment are automatic, they can't be adjusted. For HDMI output, the functions can only be adjusted while connecting with monitor, if you connect the camera with computer, the functions also can not be adjusted.

3:When use USB connection, please make sure no TF card in the camera.

Specification:

Image sensor:34 megapixel Panasonic CMOS sensor 1/2.33 inch

Effective pixel:34 megapixel

Pixel size:1.335μm × 1.335μm

Frame rate:60fps

Definition: FULL HD

Housing: metal

Lens :C/CS

Video format: MP4

Digital Zoom: Support

Brightness control: Auto/manual

Color: R/G/B adjustable

Film and record: Support

Cross cursor: Support multi-color, size adjustable

Transverse and vertical line:

Support multi-color, 5 pcs of transverse lines/vertical lines, movable

Different color,5 horizontal line , 5 vertical line, any positions

TF card interface: Max 64G

HDMI interface: Standard HDMI output (Type A)

USB interface: Standard usb2.0 interface (Type B)

Input Voltage: DC 12V

100X C-MOUNT Lens:

Magnification Power by 0.12 - 2X (about 8 - 100X on the display)

Work distance:55m-200mm

Visual field :2.4mm-32mm

Size: 115mm(L) * 40mm(DIA)

Weight: 210g

8 Inch Monitor:

LCD Type: TFT LED

Physical Resolution: 800 × 600

Display Ratio: 4: 3

Contrast Ratio: 300: 1

Field Frequency: 50Hz, 60Hz, 70Hz

Signal Interface: AV × 1, BNC × 1, VGA × 1, HDMI × 1

Color Format: PAL / NTSC / SECAM

Package Including:

1 x Microscope Camera

1 x 12V/1A Power supply

1 x USB line

1 x 100X Zoom C-mount Lens

1 x Camera Stand

1 x 40-LED Ring Light with Power Adapter

1 x 8 inch Monitor
