Technical Specification

Image and Video

Photo resolution: 24M(6544 x 3680), 20M(5888 x 3312), 16M(5376 x 3024), 12M (4608 x 2592), 8M (3840 x 2160), 5M (2960 x 1664), 3M(2400 x 1344), 2M (1920 x 1088)
Screen :2.4" IPS 320 x 240(RGB) DOT TFT-LCD Display
Lens: F=4.3; F/NO=2.0; FOV=80°; Auto IR filter
Triggering time :approx. 0.4 second; Pre boot 0.2 second Video resolutions: 1296P(1728 x 1296, 30fps), 1080P (1920 x 1080, 30fps), 720P (1280 x 720, 30fps), 480P(848 x 480, 30fps), 360P(640 x 360, 30fps)
Effectiveness Daytime: 1 m - infinitive; Night time: 3 m - 20 m
Storage formats Photo: JPEG; Video: AVI Motion JPEG


Data Storage
Recording medium: Supports SD/SDHC memory cards up to 128 GB (optional)

Audio

Microphone: 48 dB high sensitivity sound collection
Buzzer: 2700HZ, 85dB



APP
System Requirements :IOS 9.0 or Android 5.1 above
Real-time Video Preview : Only supports APP mode, Direct Video Connection, easy to install and test
APP Function :Installation target, parameter setting, time synchronization, shooting test, power warning, SD/SDHC card warning, PIR test, full screen preview
Quick Parameter Setting :Supported
Online Data Management :Video, Photos, Events: Support online Viewing, Deletion, Download


Night vision
Day / Night Mode: Day/night, Auto Switcing
IR-CUT: Built-in
IR flash: 36pcs 940nm infrared LEDs range 20m


Trigger Alarm
Detection angle of sensors: Central sensor zone: 60°; Side sensor zone: each 30° ; Total sensor angle zone: 120°
Triggering distance: up to 20 metres
PIR Sensitivity :High / Medium / Low


Power Supply and Power Consumption
Power supply: 8x batteries type LR6 (AA)
8x NiMH batteries type LR6 (AA) with low self discharge;
external 6V power supply, at least 1.5A (not supplied)
Standby time： approx. 6 months (with 8 batteries)




Package include:
Wildlife Camera *1
Mounting Belt *1
Mounting Belt *1
Instruction Manual *1
USB cable *1
