Microscope Camera Kit >> HAYEAR 4K HDMI Microscope Camera Kit for Industry Lab PCB USB Output TF Card Video Recorder +180X C-Mount Lens + Big Stereo Stand +144 LED Light
View Larger Image
Share your images of this product
HAYEAR 4K HDMI Microscope Camera Kit for Industry Lab PCB USB Output TF Card Video Recorder +180X C-Mount Lens + Big Stereo Stand +144 LED Light
Price : US $ 412.68 599.00
SKU : 2110270610
Inventory :
 Add to wish list
For bulk order or wholesale business,please contact us!
Accept PayPal payment only.
Please give me your detail address and Tel No. for safe shipping when you make the payment
Item will be shipped within two working days after payment received.Delivery time is around 7-20 business days to most countries.
Product description
1:PC Support : Windows / Mac
2:For USB output, the white balance, exposure and color adjustment are automatic, they can't be
adjusted. For HDMI output, the functions can only be adjusted while connecting with monitor, if you connect the camera with computer, the functions also can not be adjusted.
3:TF card storage is only for HDMI output. USB output will be storage in PC.

Model: HY-5299
Effective Pixels: SONY 12MP CMOS 1/2.33 IMX 4K SENSOR
Resolution: 4K/2K/1080P 1080P(HDMI)
Sensor Size: 1/2.33inch
Pixel Size: 1.55 × 1.55μm
Image Resolution: 4032 × 3024 (12MP) (16:9)
Frame rate: 30@FPS (4K)
Image Format: JPEG
WaveLength: 400nm~700nm
Frame Fate: 3840×2160@60FPS(4K); 1080P 120@FPS; 720P 240@FPS
Lens Type: C / CS
Timing Photo/Record: Support Timing Photo/Record
Storage: TF Card, Max 256G
PC Support: Windows / Mac / Linux System PC Software with Measuring
Image Measurement: Support HAYEAR Measurement
Language: EN /FR /ES /Portugues /Deutsch /Italiano /CN/Pyccknn/ JP
Output Interface: HDMI/USB Standard usb2.0 interface (Type B)
Image Scaling : 7-Fold zoom
Transverse and vertical line: Support multi-color, 5 pcs of transverse lines/vertical lines, movable
Different color,5 horizontal line , 5 vertical line,any positions
Encode: H.264 /H.265 (High Profile)
Video format: MP4
Input Voltage : DC 12V 1A
Size: 75×60×39mm(LxWxH)

Table Stand
Total height: 340mm
Column diameter: 24.7mm
Lens interface diameter:50mm
Height adjustable range:10-265mm
Stand Universal Bracket:330mm

C-Mount Lens
Objective Lens: continual zoom 0.7-4.5X
zoom ratio: 6.5:1
eyepiece lens:0.5X
amplification range:about 10X-180X on 21 inch screen
working distance: 95-115mm

Package including:

1 x4K Microscope Camera
1 x 180X C-mount lens
1 x144 LED light
1 x Power supply
1 x USB line
1 x Software DISC
1 x Remote Control
1 x Camera Stand
