HAYEAR 2022 NEW ARRIVAL 16 MP 10.1 inch Screen Digital Microscope with HDMI and Type-C interface for education, scientific research,
laboratory, PCB repair…………


Model-HY-1090
Sensor-16 Megapixel SONY IMX sensor
Pixel Size-2.0 × 2.0μm
Sensor Size-1/2.8 inch
Video Output Interface-HDMI / USB (HD Interface)
Resolution-1920x1080@60FPS（HDMI）
Monitor size-10.1 inches
USB Output-1920x1080@30FPS(USB)
Video Ratio-Support 16:9, 4:3 Mode
Picture Resolution-4608 x 3456
Frame Rate-30@FPS
Color-R/G/B support manual adjustment
Cross line-5 horizontal/vertical line, Color & size of line can be adjust, cross line with scale
Zoom-7X digital zoom
Magnifier Function-Support magnifying in same screen
Sensitivity Level-Middle(can be used with extra light source)
Interface for Lens-Standard C/CS Interface
Dynamic Range-40dB
PC Systems-Support Windows XP/7/8/10, with measurement software(gift)
Picture Format-JPEG
Language-CN, EN, JP, FR, DE, RU, IT, KR, TUR
Working Voltage-12V/1A
Spectral Response (Wavelength)-400nm~700nm (Strong)
White Balance-Manual/Auto
SNR-45dB
Mirror Image-Support Up/Down, Right/LeftBlack & White Mode-Support
Storage-TF Card, Maximum support 256GB
Working Temperature--40°C~70°C



Package including
1 x 10.1 inches monitor microscope camera
1 x type-c USB cable
1 x HDMI cable
1 x Power Supply
1 x Remote Control (Battery Not Included)
