35mm F1.7 Lens Specification:

Focal-Length: 35mm
Relative Aperture D/f': F1.7
Mount: C
Image Format: 1/1.8in
Field of View: W14.8°xT10.8°
Dimension: Approx. 35 x 22mm
Resolution: 5MP
Flange BFL: 17.53
High resolution : 5 megapixel covering 5MP & 1080P
Large format: 1/1.8" size covering 1/1.8", 1/2" camera
Big aperture : F1.7 big aperture makes imaging far better
Low distortion :<0.1% low distortion use machine vision FA automatic
Application :Biochemical, surveillance, FA, face recognition etc.

Camera Model:HY-800B
Name:USB2.0 Color 800W driver-free UVC digital camera
Image Sensor:SONY 1/1.8" Color IMX CMOS Image Sensor
Pixel size:2μm（H）×2μm(V)
Spectral response:400nm～1000nm
Scanning method:Progressive scanning, real 8MP image sensor no compression, no interpolation
Resolution:3840x2160;2592x1944;2560x1440;1920x1080;1280x720;640x480
Image format:MJPEG (Compression format) /YUV422 (Compression format)

Video recording:
3840x2160 @ 25fps;
2592x1944 @ 25fps;
2560x1440 @ 45fps;
1920x1080 HDR @ 60fps;
1280x960 HDR @ 60fps；
1280x720 HDR @ 60fps;
640x480 HDR @ 60fps
320x240 HDR @ 60fps

3840x2160 @ 1fps;
2592x1944 @ 1fps;
1920x1080 @ 5fps;
1280x720 @ 5fps;
640x480 @ 30fps
640x360 @ 60fps
320x240 @ 60fps

Dynamic Range:74 dB (Linear)-85 dB (HDR)

Sensitive:2400 mV/Lux-sec
White balance:Auto/manual
Data output:USB2.0，480Mb/s
SNR:39dB
Working temperature:-30℃～75℃
Storage temperature:-30℃～60℃
Preservable parameters:Brightness, Contrast, Color saturation,Hue, Sharpness, Gamma, Gain, White Balance, Backlight Contrast, Exposure

Support UVC:USB Video Class（UVC）
One-click white balance:Support
Exposure control:Auto/Manual
Eyepiece:0.5X eyepiece (Support 30.0mm/23.2mm diameter)
supports output formats:12-/10-bit RAW RGB
Support systems:Win XP/Win7/Win10/win11
Linux / Android (Devices that comply with the UVC protocol)
MAC OS X10.4.8 or later (Devices that comply with the UVC protocol)


Packing including:
1X 8MP USB camera
1X UBS line
1X 5MP 35mm Varifocal Lens
